PM DRAIN-TEC

zweilagig

PM DRAIN-TEC is a high-quality protection and drainage system as well as the universal solution for horizontal surface drainage for green roofs.

PM DRAIN-TEC is an effective protection and drainage system and the universal solution for horizontal surface drainage on all pressure-resistant surfaces. PM DRAIN-TEC consists of a dimpled membrane and a sturdy geotextile. The smooth back side allows for a uniform and extensive load distribution on the sealing. This double-layer system protects the waterproofing below it from mechanical damage and damaging thermal stresses.

PM DRAIN-TEC has a compressive strength of 400 kN/m². The drainage membrane is available in many different length and width variations. The excellent water draining capacity is multiple times higher than required by drainage standard DIN 4095.

PM DRAIN-TEC protects earth-covered roofs of underground car parks, patios and green flat roofs against waterlogging. The moisture penetrates the geotextile and enters the ducts of the dimpled membrane, where it is securely drained. In the process, the geotextile acts as a filter and prevents the ducts from getting clogged up. The optimal high-performance geotextile boasts very high initial strength and is subject to only minimum deformation under increasing working load.

Technical Data

Dimpled membrane	HDPE
Geotextile	polypropylene
Dimple height	8 mm
Total weight	approx. 800 g/m²
Number of dimples	1.710 dimples/m²
Compressive strength	approx. 400 kN/m² = 40 t/m²
Colour	black
Water flow capacity in the plane	approx. 2,62 l/s·m at 20 kPa rigid/soft
Roll length	12,5 / 15 / 20 m
Roll width	0,5 / 0,75 / 1,0 / 1,5 / 2,0 / 2,5 m
Air volume between the dimples	approx. 5,5 l/m²
Temperature resistance	–30 °C to +80 °C
Chemical properties	chemical-resistant
Physiological properties	safe for drinking water
Characteristic opening width	approx. 170 μm
Water permeability EN ISO 11058	approx. 100 · 10<sup>-3</sup> m/s
